TECHNIQUES SPECIFICATIONS

Physical specifications

Screen:

5.7 '' color  LCD  Display Screen

Suitable

Adult & Child

 Mode:

pneumatically powered and electrically controlled system

Working Mode:

Closed; Semi-Closed; Semi-Open

Circuit

Breathing circuit integrated standards

Flowmeters:

4 Tubes Flowmeters:  O2:0.1~10L/Min,  N2O:0.1~10L/Min;

Trolley:

Fitted with 4 nos anti-static rubber castors; two of which are lockable for braking and easy maneuverability with foot operated brake provisions

Drawer unit

ONE drawers  totally extractable

Technical Specifications:

Gas requirement:

Medical oxygen and nitrous oxide with a pressure ranging from O2: 0.32~0.6MPa ;   NO2: 0.32 MPa to 0.6 MPa.

safety valve

<12.5  kPa

Respiratory Rate

1~99bpm

oxygen concentration in the mixed gas N₂O/O₂

> 21%

Oxygen Flush:

25~75 L/min

modes of ventilation

 IPPV, SIPPV, IMV, SIMV, VCV,  MANUAL PEEP  SIGH

Inspiratory trigger pressure

-1.0kPa ~ 2.0 kPa

IMV frequency:

1-12 s/min

I/E Ratio:

4:1 ~ 1:4, Has the inverse ratio ventilation

Tidal Volume

0 ~ 1500 ML

Inspiratory Plateau:

0~1s

PEEP

1-10 hPa

Maximum safety pressure:

≤ 12.5 kPa

Ptr

 -1.0-1.0 hPa

Oxygen concentration alarm: Audible and visual and with yellow and red color indicating

upper alarm: 21% ~100%;  lower alarm:10%~80%
